How an Air Amplifier Works

Just thought I would share,




Major Features
1, Air Inlet Port
2,Air Drive Tube
3, Drive Piston
4,Upper Tappet Valve
5, Pilot Air Tube
6, Spool Valve
7, Lower Tappet Valve
8, Pilot Vent
9, Outlet Muffler
10,Inlet Check Valve
11, Outlet Check Valve

Drive Air Flow
High Pressure Air
Exhaust Flow

I am so going to have to make one of these lol,
There is like nothing to them .
