Overhead Console Wiring (Large Pics)

Alright, I have been searching through my information and gathering wiring connector diagrams for Overhead Consoles. I also have PDF documents that detail a 2003 Instrument panel, gauges, overhead console, center console and more. It’s almost 200 pages long. If anyone would like to host this file online or wants a copy, PM me. Here are some diagrams from 97 and 2002 and 03. I think these cover the different styles. If you have a style (wire colors) that’s different, contact me and I can post yours also.

1997 DIC without Mode


1997 DIC Mode Console


2002 DIC without Mode


2002 DIC Mode Console


2003 schematics




I prefer the connector views, but they are hard to find. If you need anything PM me, I’m trying to keep this thread primarily information and wiring diagrams so please don’t post unless it’s important.



2011 Silverado, 4.3 RCLB 61,xxx miles
1994 S10 160,XXX miles. Lifted 4/3
1985 Ramcharger Royal SE Prospector 440/727/NP203 (beach toy)
1982 Dodge W250 360/NP435/NP208 lifted on 36's, mud toy.
Wiring Diagrams and Misc. Repair
deathphoenix99 is offline
Sponsored Links
Advertisement

post #2 of 16 Old 11-04-2009, 12:13 PM
Registered User

goddspring's Avatar

Join Date: Jan 2007
Location: staples, mn
Age: 35
Posts: 2,574

User is: goddspring is offline
Send a message via MSN to goddspring Send a message via Yahoo to goddspring
Re: Overhead Console Wiring (Large Pics)

nice, havent seen one with the diagram for the harness yet. i have one sittin in my living room and thinkin about puttin it into the womans zr2. just need to get the sensors. i had the temp sensor, but someone stole my took box and it was in there, bastards.

Mike
99 ZQ8 std cab stepside.

00 ZR2 extended cab DOA awaiting a transplant.

If at first you don't succeed, F it and grab a beer.
goddspring is offline
post #3 of 16 Old 11-04-2009, 12:26 PM Thread Starter
Electrical Mod

deathphoenix99's Avatar

Join Date: Oct 2007
Location: Houston, TX
Age: 26
Posts: 56,124

User is: deathphoenix99 is offline
Send a message via AIM to deathphoenix99
Re: Overhead Console Wiring (Large Pics)

2002 Instrument Cluster Wiring. The Overhead console is in the bottom right of the first picture. The second picture shows the rest of the wiring.





2011 Silverado, 4.3 RCLB 61,xxx miles
1994 S10 160,XXX miles. Lifted 4/3
1985 Ramcharger Royal SE Prospector 440/727/NP203 (beach toy)
1982 Dodge W250 360/NP435/NP208 lifted on 36's, mud toy.
Wiring Diagrams and Misc. Repair
deathphoenix99 is offline
post #4 of 16 Old 11-04-2009, 03:36 PM
Registered User

VortecSonoma's Avatar

Join Date: Nov 2008
Location: Fredericksburg,Va
Age: 29
Posts: 684

User is: VortecSonoma is offline
Re: Overhead Console Wiring (Large Pics)

can i get everything you got on a 1995 Sonoma Highrider

Quote:
Originally Posted by ZQ8 Blazer View Post
STFU and go take your Cialis grandpa
VortecSonoma is offline
post #5 of 16 Old 11-09-2009, 11:55 AM Thread Starter
Electrical Mod

deathphoenix99's Avatar

Join Date: Oct 2007
Location: Houston, TX
Age: 26
Posts: 56,124

User is: deathphoenix99 is offline
Send a message via AIM to deathphoenix99
Re: Overhead Console Wiring (Large Pics)

Here are the wiring diagrams for a 2002 Astro. It has different wiring colors.

Wiring Schematic


Different style schematic


Here is a resistance table for the temperature sensor.


2011 Silverado, 4.3 RCLB 61,xxx miles
1994 S10 160,XXX miles. Lifted 4/3
1985 Ramcharger Royal SE Prospector 440/727/NP203 (beach toy)
1982 Dodge W250 360/NP435/NP208 lifted on 36's, mud toy.
Wiring Diagrams and Misc. Repair
deathphoenix99 is offline
post #6 of 16 Old 12-03-2009, 08:34 PM
Overhead Console Expert

Raven's Avatar

Join Date: Jan 2008
Location: Omaha, Nebraska
Age: 29
Posts: 1,884

User is: Raven is offline
Send a message via AIM to Raven
Re: Overhead Console Wiring (Large Pics)

if you could pm me on that i would like to get a copy of the pdf file
thanks

1999 S10 4.3L Zr2
Overhead Console Dude
Raven is offline
post #7 of 16 Old 01-03-2010, 07:32 PM
rolling work in progress

Mr.woodscrewsNbondo's Avatar

Join Date: Feb 2009
Location: nlr ar
Age: 26
Posts: 2,087

User is: Mr.woodscrewsNbondo is offline
Re: Overhead Console Wiring (Large Pics)

Quote:
Originally Posted by deathphoenix99 View Post
2002 Instrument Cluster Wiring. The Overhead console is in the bottom right of the first picture. The second picture shows the rest of the wiring.




i got this display center from a bravada. i need to know if it will work with my 2.2 s10, both 98+, also can i hook the yellow wire to the light green one at the bcm, and whats the purple wire for.

Mr.woodscrewsNbondo is offline
post #8 of 16 Old 01-04-2010, 12:58 AM Thread Starter
Electrical Mod

deathphoenix99's Avatar

Join Date: Oct 2007
Location: Houston, TX
Age: 26
Posts: 56,124

User is: deathphoenix99 is offline
Send a message via AIM to deathphoenix99
Re: Overhead Console Wiring (Large Pics)

Quote:
Originally Posted by Mr.woodscrewsNbondo View Post
i got this display center from a bravada. i need to know if it will work with my 2.2 s10, both 98+, also can i hook the yellow wire to the light green one at the bcm, and whats the purple wire for.

It should work being both are 98+, however, I don't know if anyone has actually got one to work with the 2.2. I know they work fine in the 4.3, but I'm still waiting on verification for the 4-banger.


The purple wire is for a dimming feature or something. Not really needed I believe.


The yellow wire should be able to be hooked up at the bcm, however, it'd be a lot easier to hook it up to the data port under the dash.


2011 Silverado, 4.3 RCLB 61,xxx miles
1994 S10 160,XXX miles. Lifted 4/3
1985 Ramcharger Royal SE Prospector 440/727/NP203 (beach toy)
1982 Dodge W250 360/NP435/NP208 lifted on 36's, mud toy.
Wiring Diagrams and Misc. Repair
deathphoenix99 is offline
post #9 of 16 Old 02-28-2010, 04:02 PM Thread Starter
Electrical Mod

deathphoenix99's Avatar

Join Date: Oct 2007
Location: Houston, TX
Age: 26
Posts: 56,124

User is: deathphoenix99 is offline
Send a message via AIM to deathphoenix99
Re: Overhead Console Wiring (Large Pics)

For wiring information and diagrams along with repair information.
http://docs.google.com/leaf?id=0B9SE...ut=list&num=50


2011 Silverado, 4.3 RCLB 61,xxx miles
1994 S10 160,XXX miles. Lifted 4/3
1985 Ramcharger Royal SE Prospector 440/727/NP203 (beach toy)
1982 Dodge W250 360/NP435/NP208 lifted on 36's, mud toy.
Wiring Diagrams and Misc. Repair
deathphoenix99 is offline
post #10 of 16 Old 04-21-2012, 01:04 AM
I'm "that guy"

forty6and2's Avatar

Join Date: Nov 2008
Location: Middle of Canada
Age: 41
Posts: 100

User is: forty6and2 is offline
Re: Overhead Console Wiring (Large Pics)

so? kickin that dead horse again... i pulled a mode dic out of a 2000 blazer and wired it up in my 99 s10 WITH the 2.2.. it displays, it resets, it calibrates, but none of the mpg stuff works.. after 30 seconds all displays go to --

did ANYONE ever get this working in a 2.2 truck? not sure why it wont tho,, i mean a 2.2 and a 4.3 should take in relativly the same info into the cpu right???

ide love to have the extra features, but if its not compatible ill just stick with the compass and temp dic
forty6and2 is offline
post #11 of 16 Old 04-21-2012, 01:09 AM Thread Starter
Electrical Mod

deathphoenix99's Avatar

Join Date: Oct 2007
Location: Houston, TX
Age: 26
Posts: 56,124

User is: deathphoenix99 is offline
Send a message via AIM to deathphoenix99
Re: Overhead Console Wiring (Large Pics)

So far I have only heard/seen these work with the 4.3 and the 4.3 only. Even people who do V8 swaps lose functionality of the DIC. So until someone says otherwise, these mode consoles are only for the V6. Sorry man.


2011 Silverado, 4.3 RCLB 61,xxx miles
1994 S10 160,XXX miles. Lifted 4/3
1985 Ramcharger Royal SE Prospector 440/727/NP203 (beach toy)
1982 Dodge W250 360/NP435/NP208 lifted on 36's, mud toy.
Wiring Diagrams and Misc. Repair
deathphoenix99 is offline
post #12 of 16 Old 12-19-2012, 11:30 PM
Bowtie Supply, RIP

theoriginalbowtie's Avatar

Join Date: Jan 2007
Posts: 114

User is: theoriginalbowtie is offline
Re: Overhead Console Wiring (Large Pics)

Quote:
Originally Posted by deathphoenix99 View Post
For wiring information and diagrams along with repair information.
http://docs.google.com/leaf?id=0B9SE...ut=list&num=50
When I use the google docs folders, even downloading as pdf files cuts the images short... for example, the 2002 mode 7 thru 15 connector cuts off 13 thru 15... is there a reason why and did you know this or no? I did save this thread as well as the individual pics in it but they are cut off at least for me either viewed in google folders or "saved as...pdf" from google menus...
theoriginalbowtie is offline
post #13 of 16 Old 07-17-2014, 04:19 PM
Registered User

Join Date: Jul 2014
Age: 57
Posts: 2

User is: MykTurk is offline
Re: Overhead Console Wiring (Large Pics)

Hey, first post! I have a 95 GMC Sonoma SLS extended cab, and an overhead console I bought years ago out of an I don't know what anymore... It's a long second gen Blazer/Jimmy, (maybe Bravada), with temp and compass only (US/MET & ON/OFF buttons) and this 6 wire connector:
http://i648.photobucket.com/albums/u...ithoutmode.jpg
And a second 4 wire connection with these color wires as part of the harness:
White
Orange
Black
yellow or light yellow.
These have different color wires going to the dome light and directional spots themselves in the console.
I've also see the yellow wire from both connections (4 & 6 wire) end up together down stream in the harness, before reaching the mulit wire connector at the other end.

I'm having a hard time finding information on wiring this version up at all.

Now, one thing I've found in back of the cab, where the factory dome light is (I want to eliminate this if I can and just use the console dome light instead.), there are the same 4 color wires the 4 wire plug on the console has, Orange & white powering the dome light, plus a black and yellow that look to be, just riveted to the plastic dome light bracket. I haven't (nor do I want to) removed the headliner. Can I just patch into them for the general lighting connections?
By the way, here's my truck...

Thanks!
MykTurk is offline
post #14 of 16 Old 07-17-2014, 05:30 PM
Registered User

Join Date: Jul 2014
Age: 57
Posts: 2

User is: MykTurk is offline
Re: Overhead Console Wiring (Large Pics)

Too late to edit, I've guessed, the yellow and black wire at the dome light are for the third brake light, duh.
MykTurk is offline
post #15 of 16 Old 07-18-2014, 09:07 AM
Registered User

alderfek's Avatar

Join Date: Jan 2013
Location: NW Georgia
Age: 51
Posts: 294

User is: alderfek is offline
Send a message via AIM to alderfek Send a message via MSN to alderfek Send a message via Skype™ to alderfek
Re: Overhead Console Wiring (Large Pics)

Has anyone hooked these up so it was functional(at least the compass and outside temp) in a 1st Gen ?

Kirk

North of Mason, South of Dixon, 2nd star to the right.

1st Gen Jimmy GT build http://www.s10forum.com/forum/f20/pr...mmy-gt-510067/
alderfek is offline
post #16 of 16 Old 07-23-2014, 06:19 PM
Registered User

24digger's Avatar

Join Date: Dec 2008
Location: Central Indiana
Age: 53
Posts: 2,053

User is: 24digger is online now
Re: Overhead Console Wiring (Large Pics)

Yes I did it. I don't have a detailed write up but have some pics in my baja thread.
24digger is online now
